Plot max horizon and range from the station

Plot maximum horizon and its range based on the local terrain model, the local surface model and the regional digital terrain model with infos from the weather station.

Usage

plot_station_horizon_range(stn = NULL, path = stn$path)

Arguments

stn

A SpatVector with station attributes from "get_metadata_frost"

path

A directory path defining where will be saved the plots, if path is NULL the plots are printed to the console

Value

A figure

References

https://frost-beta.met.no/docs/codeexamples

Examples

# Load the station metadata and location
stn <- get_metadata_frost(stationid = 18700, path = "plot/horizon")

# Plot sun diagram and save
plot_station_horizon_range(stn)
#> [1] "Process: 18700 - 260966.8/6652718.0 - dtm - 100/1 - path: data/dem"
#> [1] "Load demo file: data/dem/18700_dtm_25833_d00100m_1.0m.tif"
#> [1] "Process: 18700 - 260966.8/6652718.0 - dom - 100/1 - path: data/dem"
#> [1] "Load demo file: data/dem/18700_dom_25833_d00100m_1.0m.tif"
#> [1] "Process: 18700 - 260966.8/6652718.0 - dtm - 20000/20 - path: data/dem"
#> [1] "Load demo file: data/dem/18700_dtm_25833_d20000m_20.0m.tif"
#> Over-riding projection check
#> Importing raster map <elev>...
#>    0%   3%   6%   9%  12%  15%  18%  21%  24%  27%  30%  33%  36%  39%  42%  45%  48%  51%  54%  57%  60%  63%  66%  69%  72%  75%  78%  81%  84%  87%  90%  93%  96%  99% 100%
#> SpatRaster read into GRASS using r.in.gdal from memory
#> Over-riding projection check
#> Importing raster map <elev>...
#>    0%   3%   6%   9%  12%  15%  18%  21%  24%  27%  30%  33%  36%  39%  42%  45%  48%  51%  54%  57%  60%  63%  66%  69%  72%  75%  78%  81%  84%  87%  90%  93%  96%  99% 100%
#> SpatRaster read into GRASS using r.in.gdal from memory
#> Over-riding projection check
#> Importing raster map <elev>...
#>    0%   3%   6%   9%  12%  15%  18%  21%  24%  27%  30%  33%  36%  39%  42%  45%  48%  51%  54%  57%  60%  63%  66%  69%  72%  75%  78%  81%  84%  87%  90%  93%  96%  99% 100%
#> SpatRaster read into GRASS using r.in.gdal from memory
